THX® Certified Ultra in-wall Architectural Speaker

Ci3160REF-THX# utilises REFERENCE technologies to meet the standards of the legendary REFERENCE Series, as well as KEF’s Extreme Theatre and THX® Certified Ultra. It even comes with a REFERENCE Build Certificate signed by the craftsman who made it.
*This product may take 12-14 weeks for delivery.


Ci3160REF-THX takes in-wall performance to new heights. Whether used as a two-channel pair or as part of a complete home theatre system in any combination of KEF Architectural and traditional speakers, Ci3160REF-THX delivers countless possibilities for REFERENCE performance.
Select a property

Flawless Sound

Ci3160REF-THX utilises the latest Uni-Q point source driver array. A 25mm vented aluminium dome tweeter sits at the exact acoustic centre of a 125mm mid-range driver. Together they act as a single source, flooding the listening space evenly with flawlessly natural sound.
Select a property

Brilliant Bass

Ci3160REF-THX’s bespoke 160mm bass driver is optimised for in-wall performance. With a massive vented magnet assembly and a large aluminium wire voice coil driving an exceptionally light, stiff and strong alloy cone, the dynamics and power handling are exceptional.
Select a property

Auditioning perfection

Ci3160REF-THX’s crossover combines the science of computer-modelling with the rigours of exhaustive auditioning and refinement of each high-grade component. Only components with the lowest distortion and the smoothest response make the grade for this exceptional loudspeaker. #For optimised performance, THX recommends using the Ci3160REF-THX without grille or fabric grille.

The Details


Nominal Impedance
4 Ohms
90dB (2.83V/ 1m)
Frequency Response (±6DB)
40Hz – 28kHz (±6dB)
Frequency Range (-10DB)
Nominal Coverage (Degrees)
Crossover Frequencies
350Hz, 2.7kHz
Drive Units
LF: 2 x 160mm (6.5 in.)
MF: 125mm (5.25 in.) Uni-Q
HF: 25mm (1 in.)
Recommended Amplifier Power
40 – 350W
Recommended High-pass Filter (HZ)
Product External Dimension (H X W X D)
680 x 230 x 105.7 mm (26.77 x 9.06 x 4.16 in.)
Cut-out Dimensions (H X W)
660 x 209 mm (25.98 x 8.23 in.)
Mounting Thickness (Maximum)
Mounting Thickness (Minimum)
Mounting Depth from Surface
99mm (3.9 in.)
Optional Rough In Frame
Ideal Rear Volume (L)
Minimum Rear Volume (L)
Max SPL (dB)
THX Ultra
Safety and Regulatory Compliance
Net Weight
13.4Kg (29.54Ibs.)
Unit Measurement
KEF reserves the right, in line with continuing research and development, to amend or change specifications. E&OE. THX, the THX logo, and Ultra are trademarks of THX Ltd. THX and the THX logo are registered in the U.S. and other jurisdictions. All rights reserved.

Please visit our Ci Software Download page for more details.
