Aprašymas
Revel in-ceiling loudspeakers draw upon the same research, resources, and unique perspectives that put all our loudspeakers in a class by themselves. Each model offers a standard-setting low sonic coloration and freedom from distortion over a wide dynamic range.
General Specifications
| Height | Cutout dimensions (dia) 8″ (20.3 cm) Square grille finished height 9.1″ (23.1 cm) |
|---|---|
| Width | Square grille finished height 9.1″ (23.1 cm) |
| Depth | Mounting depth 4.8″ (12.2 cm) |
| Weight | 1.9 lb (0.9 kg) / Shipping Weight 2.6 lb (1.2 kg) |
| Features | Includes both round and square zero-bezel magnetic grilles • Round grille finished dimension (dia.) 9.1″ (23.1 cm) |
| High-frequency Driver Components | Two 1″ aluminum dome tweeters with waveguides |
| Low-frequency Driver Components | 6 ½” Micro-Ceramic Composite (MCC) Cone, Cast-polymer Frame Woofer |
| Mounting | C-2 fastening mechanism • Compatible with wall material thickness range 0.5″ – 2.0″ (1.3 cm – 5.0 cm) |
| Recommended Amplifier Power | 10 – 120 Watts RMS (per channel) |
