Aprašymas
Since the first Revel® speakers in 1996, Revel products have stood at the forefront of loudspeaker design and performance. Revel in-wall loudspeakers draw upon the same research, resources and unique perspective that put all Revel loudspeakers in a class by themselves. Revel in-wall loudspeakers provide unparalleled value and are known for their standard-setting low sonic coloration and their freedom from distortion over an extraordinarily wide dynamic range.
General Specifications
| Height | Grille Finished Dimensions (H x W) 15.1″ x 7.4″ (18.8cm x 7.8cm); Cutout Dimensions (H x W) 14.1″ x 6.4″ (35.9cm x 16.3cm) |
|---|---|
| Weight | 5.6 lb (2.5kg) / Shipping Weight 7.3 lb (3.3kg) |
| Features | C-2 Installation Mechanism; Compatible with Wall Material Thickness Range 0.5″ – 2.0″ (1.3cm – 2.5cm) |
| High-frequency Driver Components | 1″ Aluminum-Dome Swiveling Tweeter with Waveguide |
| Low-frequency Driver Components | 2 x 5-1/4″ Micro-Ceramic Composite (MCC) Cone, Cast-Aluminum Frame Woofers |
| Mounting | Mounting Depth 3.5″ (88mm) |
| Recommended Amplifier Power | 10 – 100 Watts RMS |
| Sensitivity | 91dB |
| Optional Accessories | Preconstruction Bracket and Fire-Rated Back-Box Accessories Available |
