Since the first Revel speakers in 1996, Revel products have stood at the forefront of loudspeaker design and performance. Revel in-wall loudspeakers draw upon the same research, resources and unique perspective that put all Revel loudspeakers in a class by themselves.
Revel in-wall loudspeakers provide unparalleled value and are known for their standard-setting low sonic coloration and their freedom from distortion over an extraordinarily wide dynamic range..
General Specifications
| Depth | Mounting depth 3.7″ (9.4 cm) |
|---|---|
| Weight | 4.4 lb (2 kg) / Shipping weight 5.5 lb (2.5 kg) |
| Features | Cutout dimensions (H x W) 9.8″ x 7.3″ (24.9 cm x 18.5 cm) • Includes zero-bezel magnetic grille • Grille finished dimension (H x W) 10.8″ x 8.3″ (27.3 cm x 21.1 cm) |
| High Frequency Driver Components | 1″ aluminum dome swiveling tweeter with waveguide |
| Low Frequency Extension | High Frequency Extension 3-position HF level control |
| Low Frequency Driver Components | 6 ½” Micro-Ceramic Composite (MCC) Cone, Cast-Aluminum Frame Woofer |
| Mounting | Cutout dimensions (H x W) 9.8″ x 7.3″ (24.9 cm x 18.5 cm) • Includes zero-bezel magnetic grille • Grille finished dimension (H x W) 10.8″ x 8.3″ (27.3 cm x 21.1 cm) |
| Recommended Amplifier Power | 10 – 130 Watts RMS |
