Aprašymas
The A11 Integrated Amplifier is based on the successful 14 Series models. The output power utilizes classic Rotel Class AB amplification rated at 50 Watts per channel into 8 ohms. Source inputs include an MM Phono Stage for classic vinyl lovers, aptX and AAC Bluetooth for wireless audio streaming and an array of 4 RCA analogue inputs for ultimate flexibility. The front panel graphic display and IR remote control ensure effortless and simplified control of your audio.
All of this is complimented by a Rotel in-house custom designed oversized toroidal transformer using steel and copper raw materials only from proven, trusted suppliers. The resulting acoustic performance speaks for itself under all loading conditions with even the most difficult speaker loads.
Specifikacija
DIMENSIONS (W × H × D)
430 × 93 × 345mm
17″ × 3.6″ × 13.5″
FRONT PANEL HEIGHT
80mm (3.15″)
POWER REQUIREMENTS
230V, 50Hz
POWER CONSUMPTION
160W
STANDBY POWER CONSUMPTION
<0.5W
NET WEIGHT
6.85kg (15lbs.)
BTU RATING (4Ω, 1/8th power)
479 BTU/h
CONTINUOUS POWER OUTPUT
50W/Ch (All channels driven, 8Ω)
TOTAL HARMONIC DISTORTION (THD)
(20Hz–20kHz) <0.03%
FREQUENCY RESPONSE
Line Level Inputs: 10Hz – 100kHz ±0.5dB
Phono Input: 20Hz – 20kHz ±0.5dB
S/N RATIO (IHF “A” Weighted)
Line Level Inputs: 100dB
Phono Input: 85dB
INTERMODULATION DISTORTION (60Hz:7kHz, 4:1)
<0.03%
DAMPING FACTOR
140
SPEAKER IMPEDANCE
4Ω minimum
INPUT SENSITIVITY
Line Level Inputs: 180mV
Phono Input (MM): 2.3mV
INPUT IMPEDANCE
Line Level Inputs: 47kΩ
Phono Input (MM): 47kΩ
INPUT OVERLOAD
Line Level Inputs: 4V
Phono Input: 50mV
PREOUT LEVEL
1V
OUTPUT IMPEDANCE
470Ω
TONE CONTROLS
±10dB at 100Hz / 10kHz
