Aprašymas
In 1989, Rotel confirmed its digital audio expertise with the launch of the RCD-855 CD player. The press was overwhelming in its praise, one critic going so far as to call it “The steal of the century”, and since then Rotel has never looked back.
The CD14 design begins with a carefully engineered power supply to ensure separate, ripple-free voltage and current to both digital and analogue circuits. It maintains the same clean lines and intuitive operation as the other 14 series models, while demonstrating an uncanny ability to resolve even the smallest musical details in a recording.
Specifikacija
DIMENSIONS (W × H × D)
430 × 98 × 312mm
17″ × 3.8″ × 12.3″
17″ × 3.8″ × 12.3″
FRONT PANEL HEIGHT
80mm (3.15″)
POWER REQUIREMENTS
230V, 50Hz
POWER CONSUMPTION
15W
STANDBY POWER CONSUMPTION
<0.5W
NET WEIGHT
5.9kg (13lbs.)
BTU RATING
51 BTU/h
TOTAL HARMONIC DISTORTION (THD)
0.002% @ 1kHz
FREQUENCY RESPONSE
20Hz – 20kHz ±0.5dB
S/N RATIO (IHF “A” Weighted)
>118dB
DYNAMIC RANGE
>99dB
DIGITAL TO ANALOG CONVERTERS
Wolfson 24-bit/192kHz
CHANNEL BALANCE
±0.5dB
CHANNEL SEPARATION
>115dB @ 10kHz
